Fujitsu TeamPoS 2000 - Primary IDE Master - M Motherboard

8.1.6 Primary IDE Master - M Motherboard
BIOS SETUP UTILITY VXX.xx
Main Advanced PCIPnP Boot Security Chipset Power
Other 
Primary IDE Master
Device : Hard Disk
Instructions will appear
Vendor: : ST310220A
in this part of the screen.
Size : XX.xGB
LBA Mode : Supported
Block Mode:16 Sectors
PI0 Mode: :4
Async DMA: MultiWord DMA-2
Ultra DMA :Ultra DMA-4
¬ ® Select Screen
S.M.A.R.T. : Supported
 ¯ Select Item
Type [Auto]
+ - Change Field
LBA/Large Mode [Auto] Tab Select Field
PIO Mode [Auto] F1 General Help
S.M.A.R.T. [Auto] F10 Save and Exit
32Bid Data Transfer [Enabled] ESC Exit
(C) Copyright 1985-2003, American Megatrends, Inc.
8-6 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: If an external USB CDROM drive is connected, it must be selected as the first
boot drive in order to boot from it. Refer to 8.1.21 for Boot Group Priority.
