Fujitsu TeamPoS 2000 - Teamusb Settings

5.5 TeamUSB Settings
Switch Definition Settings (Default in Bold)
SW1 1
2
3
4
BATL Detect Lead Acid Battery Alarm
FAN1 Detect CPU Fan Alarm
FAN2 Detect PSU Fan Alarm
FAN3 Detect Chassis Fan Alarm
ON Enable OFF Disable
ON Enable OFF Disable
ON Enable OFF Disable
ON Enable OFF Disable
JP1 1-2
3-4
5-6
7-8
9-10
11-12
13-14
15-16
17-18
19-20
Configured for setting up TeamUSB board for
using six or seven USB ports depending upon
the motherboard being used.
See silkscreen on board for actual jumper
settings.
JP2 1-2
3-4
5-6
7-8
9-10
Decodes each drawer open switch from cash
drawer. Configured for the type of cash
drawer being used. Distinguishes between FJ
cash drawer and NCR. FJ is default
SHORT FJ OPEN NCR
OPEN FJ SHORT NCR
OPEN FJ SHORT NCR
OPEN FJ SHORT NCR
SHORT FJ OPEN NCR
JP3 1-2
3-4
5-6
7-8
9-10
Determines the power source for the +12V on
USB port 6. Options are from +24V power
through a DC-DC converter or direclty from
+12V power
SHORT +12V OPEN DC-DC
SHORT +12V OPEN DC-DC
OPEN +12V SHORT DC-DC
OPEN +12V SHORT DC-DC
OPEN +12V SHORT DC-DC
90000291 Rev 3.0 5-23
TeamPoS 2000 MAINTENANCE MANUAL
