4.9 Installation with Other Equipment
In most cases, dedicated AC mains circuits are not required for the TeamPoS Series
terminals. In rare instances, other electrical equipment sharing power with the terminal
may cause adverse effects on the terminal. When this occurs, electrical isolation may be
required and is the responsibility of the customer or installing contractor.
Terminals at 115-volts
The following table details the electrical supply requirements for the TeamPoS Series
control unit with a nominal voltage supply of 115 volts.
Property Value or Description
Earthing The terminals are Class 1 equipment and must be supplied via a
socket-outlet which has a protective earthing contact connected to the
protective earth terminal of the installation.
Power System The terminals are designed for use on a power system with an earthed
neutral, i.e., a TN or TT power system according to IEC 364. The
terminals must not be directly connected to a power system with an
impedance earthed neutral, i.e., an IT power system according to IEC 364.
Rated Voltage 115 Volts
Operational Voltage Limits 100-120 VAC
Rated Current 4.6 A
Rated Frequency 60 Hz
Operational Frequency Limits 57-63 Hz
Earth Leakage Current < 1.0 mA
Power Dissipation 250 watts
Maximum HRC Fuse Rating for
External Short-circuit Protection
20 A
Main Power Cord: Length
Diameter:
Minimum Bend Radius:
3.00m (9.80 ft.)
8.0 mm (0.30 in.)
10.0 mm (0.40 in.)
4-4 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
