Fujitsu TeamPoS 2000 - M Motherboard Settings

7.3.1 M Motherboard Settings
No. Pin
Name
Meaning Default
Settings
1
JP1 KB/MS Power Select
1-2 +5V
2-3 +5V SBY
1-2
2
JP2 Power COM Port Setting
1-2 RI
3-4 Powered COM (+12V)
5-6 RI
7-8 Powered COM (+12V)
1-2
5-6
3
JP3 PC Beep Jumper Setting
H/W Monitor PC Beep to Line-out
1-2 Enable
2-3 Disable
1-2
4
JP4 USB 1&2 Power Select
1-2 +5V
2-3 +5V SBY
1-2
5
JP5 KB/MS Power Select
1-2 +5V
2-3 +5V SBY
1-2
6 JP6 VCCA Power Select
1-2 1.8V Banias
2-3 1.5V Dothan
1-2
7 JP7 Clear CMOS
1-2 Normal
2-3 Clear
1-2
8 JP8 CPU Clock Setting
1-2 100MHz
2-3 133MHz
1-2
9 JP12 Disk on Chip 2000 Jumper Setting
15-16 0DE000H - 0DFFFFH
15-16
10 JP13 PCI AUX Power Select
1-2 No Power
2-3 3.3VDUAL
3-4 3.3V
2-3
7-6 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
