5.12.1 TeamPoS 2000 with Retail I/O Board Connector Layout-A Motherboard
Name Defnition
1 PoS Peripheral Port #1
2 PoS Peripheral Port #2
3 PoS Peripheral Port #3
PoS 4 PoS Peripheral Port #4
Ports 5 PoS Peripheral Port #5
6 PoS Peripheral Port #6
PTR Printer
LCD PWR LCD Power
DRW Cash Drawer
KB Keyboard
M Mouse
COM1 Communications Port #1
COM2 Communications Port #2
PC Board LPT Parallel Interface
Ports VGA Analog Video
LCD Digital LCD Video
USB Universal Serial BUS (2)
MIC Microphone/Audio In
SPEAKER Speaker/Audio Out
LAN Local Area Network
5-76 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
