5.4.6 TeamCOMBO Board. USB Connectors – 4 Ports
Powered Retail USB connector (24 VDC or 12 VDC)
Pin # DC-Out Mode
1 5 VDC USB Power
Std. USB
Signals
2 Data -
3 Data +
4 Ground
5 24 VDC Return, USB ports 1,2, and 3
12 VDC Return, USB port 4
12 or 24 VDC
Power
6 24 VDC Power, USB ports 1, 2 and 3
12 VDC Power, USB port 4
7 24 VDC Power, USB ports 1, 2 and 3
12 VDC Power, USB port 4
8 24 VDC Return, USB ports 1, 2 and 3
12 VDC Returnr, USB port 4
5-22 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: The powered USB connector will also accommodate a standard USB
connector,.that is pins 1-4. (Top portion of the connector)
