+5VSB out of range and the value +5VSB voltage out of limit
Vcore out of range and the value Vcore voltage out of limit
VccP out of range and the value VccP voltage out of limit
System board temperature out of range and the value System temperature out of limit
CPU temperature out of limit CPU temperature out of limit
Fan #1 out of range and the value FAN#1 speed on [Alarm]/[Shutdown Enabled] is out
of limit
Fan #2 out of range and the value FAN#2 speed on [Alarm]/[Shutdown Enabled] is out
of limit
Fan #3 out of range and the value FAN#3 speed on [Alarm]/[Shutdown Enabled] is out
of limit.
Single-bit ECC error 1 bit ECC error in memory
Multi-bit ECC error 2 bit ECC error in memory
Parity memory error
ROM SUM Error EEPROM checksum error
CPU Failure
8.3 BIOS Reflash Instructions - M Motherboard
If there are BIOS problems which indicate that the BIOS may be corrupted the BIOS
needs to be reflashed.
1. Clear CMOS: This is accomplished by turning off the machine and changing the
jumper for BIOS (JP7) from the 1-2 setting (default) to the 2-3 setting. Reboot the
machine. When the machine is finished rebooting, shut it off again and reset the
jumper to the default setting (1-2).
2. Power on again and press F1 to go into the BIOS.
3. When the password screen appears strike [ENTER] for the User Name and type
[MAXPOWER} for the supervisor or administrator name.
4. When the BIOS screen appears, press F10 (Save and Exit). When asked if you want to
save the BIOS - press [ENTER].
When reflashing a newer version of BIOS, the passwords will be reset to the above
default settings. If a user name or supervisor or administrator password are used they
will need to be reset.
