5.10 Models D12 and A12 LCD Installation
The 12.1" Liquid Crystal Display (LCD) used with theTeamPoS 2000 is a TFT and has
two types of interfaces, digital and analog. Options include touch, speakers, keypad with
MSR and MSR only. Touch options are factory installed and cannot be field installed.
Three stands are available:
1. Stacked, for stacking the LCD configurations without TeamKey or MSR options on a
control unit;
2. Dispersed (90000552), for dispersing the LCD without TeamKey or MSR options in a
checkstand or counter; and
3. Kiosk stand (90000542), for dispersing an LCD with theTeamKey or MSR option.
5.10.1 Model D12 and A12 LCD Stand Option Summary
The following table summarizes the 12.1" LCD stand and options:
D12 Only
D12 w/
Keypad
D12
w/MSR A12 Only
A12 w/
Keypad
A12
w/MSR
Speakers Yes Yes Yes No No No
Touch Yes Yes Yes Yes Yes Yes
Stacked
Stand
Yes No No Yes No No
Dispersed
Stand
Yes No No Yes No No
Kiosk
Stand
Yes Yes Yes Yes Yes Yes
The following sections describe cabling requirements and installation of the LCD and
options.
