Esc : Quit ¯ ® ¬ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift) F2: Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
9.1.12 Supervisor Password
This feature should not be used. If data is input by mistake, move the JP0701 from pins
1-2 to 2-3 to delete password. See section 7.6.
9.1.13 User Password
This feature should not be used. If data is input by mistake, disconnect the lithium battery
and clear the systems CMOS memory.
9.1.14 IDE HDD Auto Detection
This feature should not be used. The installed hard disk(s) are only detected as specified
on the standard CMOS set up menu.
9.1.15 Save & Exit SETUP
When the message is displayed asking if changes should be saved, type "Y" and press the
"ENTER" key. Any data changed on the sub-menus is written into CMOS memory when
the system is rebooted.
9.1.16 Exit Without Saving
When the message is displayed asking if changes should be saved type "N" and press the
"ENTER" key. Any changes on the sub-menus are canceled.
9.1.17 BIOS Error Messages
If BIOS finds an error during a power-ON self-test (POST), an audible beep code is
emitted or a message is displayed.
When the message is displayed, the following is also displayed: “PRESS F1 TO
CONTINUE, CTRL-ALT-ESC OR DEL TO ENTER SETUP”
If BIOS detects an error during the POST, one or more messages as shown below are
displayed.
9-10 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
