No. Pin
Name
Meaning Default
Settings
11 JP14 DVOB 12C Bus Setting
1-2 M12CDATA
2-3 DDCPDATA
2-3
12 JP15 12CCLK
1-2 M12CCLK
2-3 DDCCLK
2-3
13 JP16
DVI 12C Bus Setting
1-2 MDVIDATA
2-3 MDDCDATA
1-2
14 JP17 DVI 12C Bus Setting
1-2 MDVICLK
3-4 MDDCCLK
1-2
90000291 Rev 3.0 7-7
TeamPoS 2000 MAINTENANCE MANUAL
