5.12.2 TeamPoS 2000 with TeamCOMBO Board Connector Layout-A Motherboard
PoS
Ports
Name Definition
1
PoS Peripheral Port #1
2
PoS Peripheral Port #2
3
PoS Peripheral Port #3
4
PoS Peripheral Port #4
USB1
USB, 24VDC
USB2
USB, 24VDC
USB3
USB, 24VDC
USB4
USB, 12VDC
LCD PWR
LCD Power
DRW
Cash Drawer
PC Board
Ports
KB
Keyboard
M
Mouse
COM1
Communications Port #1
COM2
Communications Port #2
LPT
Parallel Interface
VGA
Analog Video
LCD
Digital LCD Video
USB
Universal Serial BUS (1)
MIC
Microphone/Audio In
SPEAKER
Speaker/Audio Out
LAN
Local Area Network
5-78 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: Once installation is complete, the unit should be left plugged in for 24 hours
to allow lead acid battery to fully charge.
