4. To mount the hard disk again, reverse the removal procedure. When mounting the
hard disk again, be sure to insert the drive into the unit as far as it will go.
5. If this is an upgrade or the addition of a second drive, install the upgrade label that
comes with the HDD upgrade kit on the side of the unit near the serial number. See
section 5.2.1.
90000291 Rev 3.0 7-15
TeamPoS 2000 MAINTENANCE MANUAL
Note: Standard hard drive is a Seagate. HDDs from other manufacturers will have
different jumper settings. Check the manufacturer's data sheet for the correct
jumper settings.
