The values should be within the ranges listed below:
BIOS Reading
Notes Low Limit Typical High Limit
Vcore Celeron, 433 MHz
(Mendocino)
1.85V (-10%) 2.05V 2.26V (+10%)
Pentium III & Celeron 566
(Coppermine)
See note below
1.44V (-10%) 1.61V 1.76V (+10%)
VTT 1.50V (-3%) 1.55V 1.60V (+3%)
VCC3 3.20V (-3%) 3.3V 3.39V (+3%)
+5V 4.80V (-4%)t 5.0V 5.20V (+4%)
+12V 11.52V (-4%) 12.0V 12.48V (+4%)
-12V -12.48V (-4%) -12.0V -11.52V (+4%)
-5V -5.20V (-4%) -5.0V -4.80V (+4%)
Vbat Lithium Battery 2.25V (-25%) 3.0V None
5VSB Stand-By 4.80V (-4%) 5.0V 5.20V (+4%)
System Temp None Varies 60
o
C
CPU 1 Temp None Varies 60
o
C
CPU 2 Temp Not Used None 0
o
C None
Fan 1 Speed CPU Fan 3150 (-30%) 4500
RPM
None
Fan 2 Speed PSU Fan 3150 (-30%) 4500
RPM
None
Fan 3 Speed Chassis Fan 3150 (-30%) 4500
RPM
None
9-8 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: The temperature, fan speed, and voltage values are actual dynamic values and
will vary. The fan speeds may vary as much as ±10% from the above values. If
fan speed drops below 30% of above values, replacement of fan is
recommended.
