DESCRIPTION FUJITSU
PART
PIN COMMENTS
UPG TP2K CDR/Read
Interface CD-ROM/DVD PCB
Cable, IDE, CD-ROM/DVD, 110mm
Cable, CD ROM/DVD Audio
90000189K
CA21258-B70X
CA05951-3291
90000191
90000189K
n/a
n/a
n/a
Reference only
Reference only
Reference only
UPG TP2K DVD
Interface CD-ROM/DVD PCB
Cable, IDE, CD-ROM/DVD 110mm
Cable, CD ROM/DVD Audio
90000165K
CA21258-B70X
CA05951-3291
90000191
90000165K
n/a
n/a
n/a
Replaced by 90000981K
Reference only
Reference only
Reference only
UPG TP2K CD-R/CD-RW&Software
CABLE, CD ROM RIBBON,
LENGTH= 110mm
CABLE, CD ROM AUDIO
PWA, CD-ROM Connector Board
90000659K
CA05951-3291
90000191
CA21258-B70X
90000659K
n/a
n/a
n/a
Replaced by 90000981K
Reference only
Reference only
Reference only
UPG TP2K FDD/3.5"/1.44 90000187K 90000187K
Cable, FDD, 220mm CA05951-3311 n/a
OPN PCIX-690 PCI Video Card 90000471 90000471 Withdrawn
OPN TP2K FRONT DOOR W/LOCK
Locking Front Panel Assembly
Front Door Lock Assembly
90000219
CA32154-D003
90000371
90000219
n/a
n/a
Reference only
Reference only
OPN TP2K SHORT CONNECTOR
COVER
90000242 90000242 Replaced by CA32154-E106
OPN TP2K Rear Cover/Standard/Short CA32154-E106 CA32154-E106
OPN TP2K Rear Cover/Compact CA32154-E007 CA32154-E007
OPN TP2K Rear Cover/Std/Long CA32154-E105 CA32154-E105
OPN TP2K
BRACKET/STD/KYB&CRT
Guide, Keyboard
Guide, CRT
Recessed Flathead Machine Screws,
Crossed Head (2 per bracket)
90000181
CA32154-Y154
80213347
F6-SSA3-05111
90000181
n/a
n/a
n/a
Reference only
Reference only
Reference only
OPN TP2K
BRACKET/COM/LCD&KYB
Guide, Keyboard
Guide, LCD
Recessed Flathead Machine Screws,
Crossed Head (2 per bracket)
90000217
CA32154-Y154
CA32154-Y152
F6-SSA3-05111
90000217
n/a
n/a
n/a
Reference only
Reference only
Reference only
OPN TP2K 14” CRT stacking tray
14" CRT Stacking Tray
80329710
80329711
PB600307
n/a Reference only
10-4 Rev 3.0 90000291
