7. Slightly pull the top cover toward the front (in the direction indicated by the arrow), then
lift and remove the cover.
8. To mount the top cover again, reverse the removal procedure.
5-6 Rev 3.0 90000291
TeamPoS 2000 MAINTENANCE MANUAL
Note: There is a locking tab on the inside of the top cover. Ensure that the tab on the
back of the top cover goes under the chassis prior to pushing it into place.
