Repair and Adjustment Procedures
Advanced Punc
h Service Ma
nual
© Copyright 2009 GBC. All rights reser
ved.
4-11
7.
Rotate the rea
r of Bypass panel [1] so that it e
xtends past t
he entrance side of
the punch [2].
Figure 4.12 Rotate the Bypass Panel Ou
t the Entrance Side of the Punch.
[2]
[1]
68
