GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
Chapter 3 LOGIQ Totus Setup 3 - 35
3-6-4 Barcode reader
The barcode reader can be used to populate the following:
• Patient screen: Patient ID, First Name, Last Name, Middle Name, Perf. Physician, Ref. Physician.
• Worklist: Patient ID, Search String.
• Image Display: Comments (Annotation)
To connect the barcode reader:
1.) Connect the barcode reader to any USB port. For example, on the user USB ports on the left or right
side of the operator panel.
2.) Boot up the Ultrasound system.
3.) Scan the barcode that comes with the barcode reader to activate device.
NOTE: Consult the barcode reader manufacturer’s instructions. This configuration process will vary
based on the barcode reader model/manufacturer and the keyboard language set on the
Ultrasound system.
Once the configuration process is complete, the barcode reader is ready to use to start a new
patient.
You do not need to repeat this process if software is reloaded, this barcode reader can be used on
any scanner as long as they have the same keyboard language selection.
