Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
4 - 28 Section 4-3 - Functional Checks
4-3-20 Basic measurement functional checks (continued)
Worksheets
Measurement/Calculation worksheets are available to display and edit measurements and calculations.
There are generic worksheets as well as Application specific worksheets. The worksheets are selected
from the Measurement Touch Panel.
Report Pages
Measurements/Calculations that are included on the worksheet can also be displayed on Report Pages.
Report Pages can be customized to meet the appropriate needs of the user.
4-3-21 Multi image functional checks
1.) Press L to activate a dual screen. The single image is placed on the left side.
2.) Press R. The left side image is freezed and the image displays in the right side.
3.) Press B key to return to the single screen.
4.) Press and hold down L to activate a quad screen. The single image is placed on the upper left.
5.) Press B key to return to the single screen.
4-3-22 ECG functional checks
The ECG capability on this LOGIQ Totus is intended as a trigger for measurements, but can also be
viewed on the screen.
Parts needed: ECG cable and M5Sc-D
ECG Checks
Table 4-9 ECG Functional Checks
Step Task Expected Result(s)
1.
Select Preset, select Cardiac, select Scan.
2.
If you do not the ECG line, select the ECG tab, you
should selection on touch screen for DISPLAY ECG.
Select and press.
You should then the line.
3.
Plug in the ECG cables with nothing attached so you
pick up noise.
The line should display noise.
4.
Connect the ECG harness to the connector on the front
of the Ultrasound system.
The LOGIQ Totus displays a straight curve along the bottom
edge of the image sector on the screen.
5.
Connect the three leads to an ECG simulator, or fasten
the three ECG Pads to your body and connect the three
leads to respective ECG Pad.
When connecting, the signal on the screen will be noisy.
When the connection is completed, a typical clean ECG signal
is displayed.
