GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
4 - 18 Section 4-3 - Functional Checks
4-3-7 Probe/connector functional checks
NOTE: Probes can be connected at any time, whether the LOGIQ Totus is ON or OFF.
For information about connecting a probe, 3-5-6 "Connecting probes" on page 3-16.
To perform the function checks for a probe/connector:
Probes requiring a leakage test
If the probe requires a leakage test, Section 10-6 "Electrical Safety Tests" on page 10-21.
Table 4-6 Probe and Connector Functional Checks
Step Task Expected Result(s)
1.
Select the appropriate connected probe from the probe indicators on
the Touch Panel.
The probe activates in the currently-selected operating mode. The
probe's default settings for the mode and selected exam are used
automatically.
2.
Launch the application.
To change application without changing the current probe, press THE
DESIRED MODE
on the Operator Panel.
The selected application starts.
3.
Verify no missing channels. All channels is functioning.
4.
Verify there is no EMI/RFI or artifacts specific to the probe. No EMI/RFI or artifacts.
5.
Test the probe in each active connector slot.
Section 3-5-6 "Connecting probes" on page 3-16.
It will display pictorial data each time.
6.
Repeat this procedure for all available probes.
