8 - 50 Section 8-5 - Replacing Cables
8-5-8 Replacement of the UBE To OPIO Touch Panel HDMI Cable
This table includes information specific to these instructions. For more information 8-2-6 "Tools needed
for servicing the LOGIQ Totus" on page 8-5 /8-2-7 "PPE Required During Service" on page 8-6.
8-5-8-1 Preparations
1.) Power off/Shutdown the system as described in 1-7-2 "Lockout/tagout procedure" on page 1-25
2.) Remove the OPIO Top Cover Set-T as described in 8-7-2 "Replacement of the OPIO Top Cover
Set-T" on page 8-89
3.) Remove the UOPIO-T Assy as described in 8-7-10 "Replacement of the UOPIO-T Assy" on page
8-98
4.) Remove the Elevation Arm Cover Set-U as described in 8-8-20 "Replacement of the Elevation Arm
Cover Set-U" on page 8-148
5.) Remove the Top Cover Assy-T as described in 8-8-17 "Replacement of the Top Cover Assy-T" on
page 8-145
6.) Remove the T2 Side Cover R Assy as described in 8-8-8 "Replacement of the T2 Side Cover R
Assy" on page 8-136
Table 8-26 Manpower, Time, Tools, and PPE
Manpower Time Tools PPE
One person Approximately 30 minutes
Phillips screwdriver
Nipper
Cut resistant gloves
Knee Pad
To Next Page
