Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
2 - 2 Section 2-2 - General LOGIQ Totus Requirements
Section 2-2
General LOGIQ Totus Requirements
Contents in this section
2-2-1 LOGIQ Totus environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2-2-2 Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-2-3 EMI limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2-2-4 Probe environmental requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2-2-5 Time and manpower requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2-2-1 LOGIQ Totus environmental requirements
If the LOGIQ Totus is very cold or hot
When unpacking the LOGIQ Totus, allow the temperature to stabilize before powering up.
Refer to Table 2-1 for guidelines on reaching operational temperatures from storage or transport
temperatures.
Environmental specifications
The LOGIQ Totus should be operated, stored, and transported according to the listed environmental
requirements.
NOTE: Probe environmental specifications may be different than the LOGIQ Totus.
Refer to Table 2-2 for environmental specifications.
CAUTION
RISK OF DAMAGE TO EQUIPMENT
IF THE ULTRASOUND SYSTEM IS VERY COLD OR HOT, DO NOT TURN ON ITS POWER UNTIL
IT HAS HAD A CHANCE TO ACCLIMATE TO ITS OPERATING ENVIRONMENT.
Table 2-1 LOGIQ Totus Acclimate Time
o
C
50 45 40 35 30 25 20 15 10 5 0 -5 -10
o
F
122 113 104 95 86 77 68 59 50 41 32 23 14
Hrs 4 2 0 0 0 0 0 0 0 2 4 6 8
Table 2-2 Environmental Specifications for the LOGIQ Totus
Operational Storage Transport (< 16 hrs.)
Temperature
10° - 35°C
50° - 95°F
-10° - 50°C
14° - 122°F
-10° - 50°C
14° - 122°F
Humidity 30 - 80% non-condensing 10 - 90% non-condensing 10 - 90% non-condensing
Pressure 70 - 106kPa 70 - 106kPa 70 - 106kPa
Heat Dissipation 3070 Btu/hour n/a n/a
