GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
Chapter 3 LOGIQ Totus Setup 3 - 83
3-7-10 Summary
Use Summary to view the Connection Manager configuration.
NOTE: To go directly to one of the configuration pages, select the related icon on the Summary page.
Figure 3-21 Connection Manager - Summary
Refer to the table below for a description of the icons shown on the Summary page.
Table 3-48 Icons on Connection Manager - Summary
Icon Description
When the icon is green, the device is online and all associated services are
available.
When the icon is red, the device is offline and all services are offline for the device.
When the icon is orange, one or more services are offline for the device.
When the icon is grey, no services are available (or a service is being updated)
for the device.
To Next Page
