6-2-4 Advanced monitor adjustments (continued)
Test patterns
Test patterns are available to aid in evaluating the display visually and quantitatively.
For complete information the appropriate version of the LOGIQ Totus Basic User Manual, Chapter 3.
1-4-1 "Label Location" on page 1-13.
Table 6-3 Test Patterns
Test
Pattern
Description Corresponding Graphic
Gray Bars
Confirm that you can clearly all of the different
gradations of the grayscale in each gray cell.
Color Bars
Confirm that you can clearly all of the different colors
in each colored cell.
Resolution
Confirm that this image is clear and crisp, without
jagged edges or lines.
