Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
10 - 28 Section 10-6 - Electrical Safety Tests
When using Dale 600/601 or a similar test instrument, its power plug may be inserted into the wall outlet
and the equipment under test is plugged into the receptacle on the panel of the meter. This places the
meter in the grounding conductor and the current flowing from the case to ground will be indicated in
any of the current ranges. The maximum allowable limit for enclosure leakage current is shown in
Table 10-9 on page 10-22
10-6-5-3 Data Sheet for Enclosure Leakage Current
The test passes when all readings measure less than the value shown in Table 10-9.
Record all data on the Ultrasound Inspection Certificate.
Table 10-14 Typical Data Sheet for Enclosure Leakage Current
Tester
Neutral
Tester Polarity
Switch
Protective Earth
Switch
Test 1
Wheel
Test 2
LCD
Optional
Test 3
Optional
Test 4
Enter Name of tested peripheral here:
Closed Normal Closed
Closed Normal Open
Closed Reversed Closed
Closed Reversed Open
Open Normal Closed
Open Reversed Closed
To Next Page
