16. Remove front stabilizer bar.
(a) Remove 4 bolts, bracket and bush.
(b) Remove stabilizer bar.
17. Install front stabilizer bar.
(a) Install bracket and bush with 4 bolts.
Hint: install bush to bush stop ring outside of
stabilizer bar.
18. Install sub frame assembly [64000087]
(see Page 205).
Front suspension - Front stabilizer bar
19. Connect lower left control arm assembly [64000091] (see Page 94).
20. Connect lower right control arm assembly [64000092] (see Page 94).
21. Connect power steering oil pipe assembly (see Page 205).
22. Connect steering oil return pipe (see Page 205).
23. Connect left side transversal lever assembly (see Page 113).
24. Connect right side transversal lever assembly (see Page 113).
25. Install front left stabilizer link assembly
[64000097].
(a) Install front stabilizer link with 2 nuts.
Torque: 74 5 N.m
Hint: if ball joint rotates with nuts, please fix bolts with
hexagonal wrench (6mm).
26. Install front right stabilizer link assembly
[64000097].
Hint: the installation procedures of right side are the
same as that of left side.
27. Install right engine bottom shield.
28. Install left engine bottom shield.
29. Install front wheels.
Torque: 103 10 N.m
97
Rear
side
Bush stop ring
Outside
