Rear suspension - Rear shaft assembly
Rear shaft assembly
Overhaul
1. Remove rear wheels.
2. Disassemble rear left brake caliper assembly
(see Page 144).
3. Disassemble rear right brake caliper assembly
(see Page 144).
4. Disassemble rear wheel speed sensor wire harness
(a) Uncouple sensor joint.
(b) Remove 2 bolts and disassemble wire harness retaining
clip.
5. Remove rear left/right brake assembly [64000137/
64000139].
(See Page 144)
6. Remove rear stabilizer bar assembly (see Page 105).
7. Disassemble rear left/right strut assembly
(see Page 102).
8. Remove rear shaft assembly [64000120].
(a) Support rear shaft assembly with a jack.
(b) Remove 2 bolts, gasket and rear shaft.
Special
tool
106
