Rear suspension - rear suspension system
Rear suspension
Rear suspension system
Table on trouble occurrence
This table could help you find out failure causes, and each figure in the table indicates the possible
sequence of failure causes, please check every part as the sequence, and replace if necessary.
Trouble occurrence Possible trouble part Pages to refer to
1. Tire (abrasion or improper tire pressure) 109
Wandering 2. Wheel alignment (incorrect) 101
3. Shaft hub bearing (abrasion) 129
4. Suspension parts (abrasion) -
1. Vehicle (overload) -
Bottoming 2. Spring (elastic fatigue) 102
3. Absorber (abrasion) 102
Swaying left and right/ 1. Tire (abrasion or improper tire pressure) 109
shaking forward and 2. Rear stabilizer bar (bending or breakage) 105
backward 3. Absorber (abrasion) 102
1. Tire (abrasion or improper tire pressure) 109
Rear wheel shimmy 2. Wheel (poor balance) 109
3. Absorber (abrasion) 102
4. Wheel alignment (incorrect) 101
1. Tire (abrasion or improper tire pressure) 109
Abnormal tire abrasion 2. Wheel alignment (incorrect) 101
3. Absorber (abrasion) 102
4. Suspension parts (abrasion) -
100
