Electric sunroof (optional)--Sunroof system
Inspection for sunroof switch
(a) Check the function of switch. Disassemble front top light,
and disassemble the joint of front top light, then check the
joint at the side of switch liking that shown in figure.
Malfunction phenomenon table
Position of parts
Malfunction phenomenon
Sunroof system does not work
Sunroof system works abnormally
Possible malfunction part
1. Ignition switch.
2. Control switch of sunroof.
3. 25A, 15# fuse.
4. Wiring harness
1. Control switch of sunroof.
2. Wiring harness
Reference page
-
-
-
-
-
-
 365 
Terminal connected by avometer
2-4
2-5
Condition
Spot contact or press
keystroke 2 for long time
Spot contact or press
keystroke 1 for long time
Regulated situa-
tion
Conduction
Conductiion
Shell body of sunroof
Motor of sunroof
Switch of sunroof
