Drive shaft--Driveshaft
Drive shaft
Drive shaft
Notes
Note: if happening any malfunction, it is necessary to change the exterior joint assembly of trans-
mission shaft.
1. Check front drive shaft assembly.
Malfunction phenomenon table
Malfunction phenomenon Possible malfunction part Reference page
Offset
1. Steering connecting rod (loosened or abraded) -
2. Bearing of shaft hub (abraded) 123
1. Ball joint (abraded) 123
Shake of front wheels 2. Bearing of shaft hub (abraded) 123
3. Steering connecting rod (loosened or abraded) -
Abnormal noise
1. Inner joint (abraded) 113
2. Exterior joint (abraded) 113
Exterior joint assembly
58
111
