Driveshaft--Left front shaft hub assembly
Left front shaft hub assembly
Change
Hint: changing procedure for right side is same as the left
side.
1. Disassemble front wheels
2. Disassemble fixing nuts of left front drive shaft
[64000083]
(a) Use special tool and hammer to unclench concave part of
fixing nuts.
(b) Disassemble fixing nuts.
3. Disassemble speed sensor assembly of left front
wheel [67000020]
(a)Disassemble the bolts, then disassemble the wiring har-
ness of sensor and brake hose.
(b)Disassemble the bolts, then disassemble speed sensor
from steering knuckle.
4. Disassemble left front brake caliper assembly
Disassemble two bolts to disassemble brake caliper bracket.
Special
tool
123
