Exterior/inner trim board--Top left trim tape
Top left trim tape
Change
Hint:
z When assembling, please work by the sequence which is opposite with disassembling
sequence; if necessary, it will have assembling instruction.
z Changing procedure for right side is same as left side.
1. Disassemble top left trim tape [68000128]
(a) Use protective adhesive tape to affix around the trimtape.
(b) Use disassembling tool for trim tape to release the front and
rear fixing clamp of trim tape, then disassemble top left trim
tape.
Note:
z Do not disassemble fixing clamp.
z If fixing clamp is damaged when disassembling,
change it with new one.
2. Assemble top left trim tape [68000128]
Note: when only changing fixing clamp.
(a) Disassemble adhesive tape remaining on the surface of
body affixed trim tape, then use white gasoline to clean the
surface.
(b) Use heating light to heat the assembling surface of fixing
clamp and automobile body.
Automobile body: 40-60°C.
Trimtape: 20-30°C.
Note: do not heat the trim tape and body too much.
(c) Put the fixing clamp on the position shown in figure, then
press it into position with hand.
(d) After pressing the fixing clamp into position for over 30
minutes, then assemble top left trimtape.
Hint:
z Surface induration time: 30 minutes.
z Complete induration time: 24 hours.
387
