Screw support cover of output rear shaft in differential shell until reaching screwing torque that is
40N•m, then put stop disc spring of output shat bearing in support cover of output rear shaft by the
direction in figure, lastly, press down end cover and tighten connecting bolts of end cover, their
torque is 12N•m
Transmission—Assemble the assembly
Transmission
Assemble the assembly
191
Connecting bolt of end cover
End cover
Stop disc spring of output
shaft bearing
Support cover of output
rear shaft
