Brake--Remove malfunction
1. Add brake liquid in storage tank.
Brake liquid: DOT-4
2. Discharge the air in brake main pump.
Hint: if brake main pump or liquid storage tank is
disassembled, it is necessary to discharge the air in
brake main pump.
(a) Disassemble brake pipeline of brake main pump.
(b) Step down brake pedal slowly and keep this state.
(c) Plug oil hole with finger, then release brake pedal.
(d) Repeat (b) and (c) three times or four times.
3. Discharge the air in brake pipeline.
(a) Connect plastic pipe on exhaust bolt of brake branch pump.
(b) After stepping brake pedal several times, and step down
brake pedal, then release inflating bolt to discharge air.
(c) Lock exhaust bolt until brake liquid stops flowing out, then
release brake pedal.
(d) Repeat (b) and (c) until air is discharged completely.
(e) Repeat the procedure above, and release the air in brake
pipeline of every wheel.
Torque: 12.7-17.6 N
⋅⋅
⋅⋅
⋅m
4. Check the brake liquid storage tank
Check the liquid level in storage tank, if necessary, add brake
liquid.
Brake liquid: DOT-4.
Brake liquid
Discharge the air in brake system
Hint: if any part of brake system has been damaged or
you disbelieve whether there is any air in brake pipeline,
it is necessary to discharge the air in brake system
completely.
Note: do not make brake liquid spill on paint surface, if
having, wash it cleanly.
135
