Exterior/inner trim board--Front bumper
Change
Hint:
z When assembling, please work by the sequence which is opposite with disassembling
sequence; if necessary, it will have assembling instruction.
z Please refer to subassembly figure of front bumper on page 379.
1. Disassemble radiator cover assembly [68000094]
(a) Disassemble the bolt and radiator cover assembly.
2. Disassemble inner gasket of left front wheel [68000225]
(a) Use disassembling tool for fixing clamp to disassemble two fixing clamps.
(b) Disassemble the screw and a part of inner gasket of left front wheel.
Hint: Disassemble the fixing clamp of screw and inner gasket of left front wheel in the scope of
front bumper which could be disassembled.
3. Disassemble inner gasket of right front wheel [68000228]
4. Disassemble front bumper [68000005]
(a) Disassemble four screws and two fixing clamps.
(b) Disassemble fixing clasp and front bumper.
(c) Equipping with fog light: disassemble two joints of fog light.
(d) Equipping with radar probe head: disassemble two radar probe heads (luxury type).
5. Disassemble reversing radar probe head assembly.
(a) Disassemble two fixing pedestals of radar probe head and two radar probe heads.
6. Disassemble left front fog light assembly [67000098]
(a) Disassemble fixing clasp and left front fog light assembly.
7. Disassemble right front fog light assembly [67000099]
î 380 î
