Panel/combination instrument--combination instrument
Indicator light:
Phenomenon
Turning light fails
Distant light fails
Possible parts of trouble
1. harness or joint
2. turn light and safety warning light system
3. combination instrument assembly
1. harness or joint
2. left combination switch
3. combination instrument assembly
Reference pages
-
-
335
-
-
335
Instrument:
Phenomenon
Revolution counter, petrol guage and
engine water thermometer fail
petrol guage fails or works abnormally
Possible parts of trouble
1. harness or joint
2. (panel) safety fuse
3. combination instrument assembly
1. harness or joint
2. Fuel guage sensor
3. combination instrument assembly
Reference pages
-
-
335
-
335
335
Vehicle inspection
1. inspect speed counter
(1) Use speedometer tester to inspect allowed error of speedometer and action of speedometer
Reference: Km/h
speed indicated by speedometer actual speed
20km/h 17-23km/h
40km/h 35-40km/h
60km/h 55-60km/h
80km/h 75-80km/h
100km/h 95-100km/h
120km/h 114-120km/h
140km/h 133-140km/h
160km/h 152-160km/h
Notes: tyre wear or tyre pressure too high or too low will increase error.
(2) Inspect speedometer needle offset
Reference: below 0.5km/h
335
