Engine mechanism - Engine assembly
Engine assembly
Replacement
1. Take measures to prevent gasoline leaking.
2. Remove engine right bottom shield.
3. Remove engine left bottom shield.
4. Discharge coolant.
5. Remove front wheels.
6. Remove engine plastic hood components.
7. Remove battery.
8. Remove air filter assembly.
9. Remove air filter hose.
10.Remove battery tray.
11. Disassemble fuel hose assembly.
12.Remove throttle cable assembly.
13.Disassemble radiator hose inlet end.
14.Disassemble radiator hose outlet end.
15.Disassemble cold air pipe inlet hose.
16.Disassemble cold air pipe outlet hose.
17. Remove transmission control pull cable assembly.
18.Disassemble warm air water inlet hose [4G18-1300102].
19.Disassemble warm air water outlet hose [4G18-1300108].
20.Disassemble the hoses of all joints to connect vehicle body end.
21.Uncouple engine wire harness.
(a) Remove glove compartment door.
(b) Remove engine wire harness from engine ECU and junction block.
(c) Pull out engine wire harness.
(b) Remove engine wire harness from junction block of engine room.
(e) Remove vehicle body earth wire.
36
