Hint: after assembling, check and adjust the height, free travel of brake pedal and the height from
pedal to floor.
Brake--Remove malfunction
Brake pedal bracket
Brake pedal bushing
Brake pedal shaft
Locking shaft
Brake main pump lever pin
Brake pedal
Brake pedal
Rubber gasket
137
N
.
m:
Regulated torque
Do not use the part repeatedly
Lithium soap base glycol lubricating grease
147
149
