Front suspension - front suspension system
Front suspension
Front suspension system
Table on trouble occurrence
This table could help you find out failure causes, and each figure in the table indicates the possible
sequence of failure causes, please check every part as the sequence, and replace if necessary.
Trouble occurrence Possible trouble part Pages to refer to
1. Tire (abrasion or improper tire pressure) 109
2. Wheel alignment (incorrect) 87
Deflection/single side 3. Steering linkage (looseness or abrasion) -
4. Shaft hub bearing (abrasion) 123
5. Suspension parts (abrasion) -
6. Steering gear (poor adjustment or breakage) -
1. Vehicle (overload) -
Bottoming 2. Spring (elastic fatigue) 90
3. Absorber (abrasion) 90
1. Tire (abrasion or improper tire pressure) 109
Swaying left and right/ 2. Stabilizer bar (bending or breakage) 96
shaking forward and backward
3. Absorber (abrasion) 90
1. Tire (abrasion or improper tire pressure) 109
2. Wheel (poor balance) 109
3. Absorber (abrasion) 90
Front wheel shimmy 4. Wheel alignment (incorrect) 87
5. Ball joint (abrasion) 99
6. Shaft hub bearing (looseness or abrasion) 123
7. Steering linkage (looseness or abrasion) -
8. Steering gear (poor adjustment or breakage) -
1. Tire (abrasion or improper tire pressure) 109
Abnormal tire abrasion 2. Wheel alignment (incorrect) 87
3. Absorber(abrasion) 90
4. Suspension parts (abrasion) -
86
