Firstly, loosen the connecting bolt of cover, and take out cover and stop disc spring of output shaft
bearing, secondly, put special wrench whose surface has four cylindrical column heaves in four holes
of support cover of rear shaft of output shaft and screw it out; lastly, loosen fastening bolt of shift cover,
take out shift cover assembly, and loosen connecting bolt of transmission to take out transmission
shell.
Transmission—Disassemble assembly
Transmission
Disassemble assembly
165
Connecting bolt of cover
Cover
Fastening bolt of shift cover
Stop disc spring of output shaft bearing
Support cover of rear shaft of output shaft
Connecting bolt
