Transmission—Disassemble assembly
Take out interlocking pin with magnetic stick
Take out clip spring of fork shaft, liking that shown in figure.
Clamp the upside of fork shaft which is protected by some
cloths and take it out, liking that shown in figure.
Take out reverse gear and reverse gear shaft
Disassemble two bolts and swing arm bracket of reverse gear,
liking that shown in figure.
166
