Exterior/inner trim board--Left lower fender of automobile body
Change
Hint:
When assembling, please work by the sequence which is opposite with disassembling sequence;
if necessary, it will have assembling instruction..
Changing procedure for right side is same as the left side.
Please refer to the subassembly figure of body left lower fender on page 388.
389
1. Disassemble mudguard of left front wheel [68000221]
(a) Disassemble three screws and mudguard of left front wheel.
2. Disassemble body left lower fender [68000049]
(a) Use disassembling tool for fixing clamp to disassemble eight
fixing clamps.
(b) Disassemble the screw.
(c) Use disassembling tool for trim tape to disassemble body
left lower fender.
