Engine mechanism - Crankshaft front oil seal assembly
Replacement
1. Remove engine right bottom shield.
2. Remove drive belt.
Slowly turn drive belt tensioner clockwise to loosen it. Then
remove drive belt and put back drive belt tensioner slowly and
gently.
3. Remove right engine mounting assembly.
(a) Remove PS oil pump reservoir and put it aside.
(b)Place wooden block between jack and engine, properly
place the jack, and then remove right engine mounting
assembly.
4. remove damping pulley.
(a) Remove pulley bolts with special tool.
(b) Remove damping pulley with special tool.
Special
tool
Special
tool
60
Crankshaft front oil seal assembly
