Press a new clip spring in input shaft by the direction in figure.
Press front tapered bearing in output shaft with method in
figure.
Note: make sure the bearing inner ring has been put into
position.
Press rear tapered bearing in output shaft with method above.
Note: make sure the bearing inner ring has been put into
position.
Transmission—Disassemble assembly
183
