there are some malfunctions, indicating light will indicate them. If exterior malfunctions are historical,
after they are removed, indicate will disappear.
one displayed or historical malfunction is only set up again by server. Inner malfunction or “impact
record” of safety airbag controller (KD4.1) could not be set up again, in this situation, it is necessary to
change safety airbag controller (KD4.1).
(3) micro controller, independent indicating light illuminates.
Microprocessor having obvious malfunction state could not work, so it could not control the work of indicat-
ing light. In this situation, indicating light will illuminate directly by applicable circuit without considering the
micro-processor, liking that shown in following:
The battery providing electricity for safety airbag controller (KD4.1) disables: indicating light illumi-
nates by the automatic light driving function.
Inner working voltage loses: indicating light illuminates usually.
New setup caused by the unsuccessful watchdog trigger: indicating light flashes
Micro-processor does not work: indicating light illuminates usually
Insert of connecter of safety airbag controller (KD4.1) is wrong: indicating light illuminates usually by
short circuit stick.
Take example to specify diagnostic step:
If finding indicating light of safety airbag illuminates usually, even if it extinguishes at last, you could check
by follow step. First is to check the part happening malfunction with diagnostic tool.
Then make by the checking step for corresponding position.
a. If scan result is inner malfunction or safety airbag has exploded, at this time, change the ECU directly.
b. Malfunction has been removed.
Supplemental restraint system--Repair
248
