Supplemental restraint system--Scrap treatment for safety airbag
Special
tool
Safety airbag
assembly at the
side of passenger
Battery
Over 10m
(5) Put two tyres at least under the tyre fixed with airbag
assembly, and put two tyres at least on the tyre fixed with
airbag assembly, at the same time, top tyre should have
wheel hub. Use two wiring harnesses to bind tyre tightly, if
shake is produced when airbag explodes, airbag module
will break off to make danger.
Width: 185mm
Inner diameter: 360mm
(6) Cut off the joint of wiring harness used for unfolding of safety
airbag assembly at the side of driver at the place apart from
the automobile, then connect it with two ends of battery.
(7) Treatment for explosive module.
Disassemble the safety airbag module at the side of driver
from wheel, and put it in ethane plastic bag, then bind the
bag for treatment with other parts.
269
