Geely FC - Page 287

Safety belt--Rear safety belt

.
 : Regulated torque
1
13
12
2
3
5
8
7
8
5
6
4
10
11
9
1. Inner trim board assembly of left rear column
[68010026]
2. Inner trim board assembly of right rear column
[68010027]
3. Left backrest assembly of rear row seat
[68010078]
4. Right backrest assembly of rear row seat
[68010079]
5. Combination part of Hexagon head bolt and flat
washer M6*14 [Q1400614]
6. Backrest assembly of rear row seat [68010076]
7. Step bolt of hexagon flange face [68000203]
8. Combination part of hexagon bolt with flat big
washer M10*1.25*22 [Q1401022]
9. Cushion assembly of rear row seat [68010074]
10.Rear safety belt crimper assembly [68010048]
11. Middle waistband of rear row safety belt with
locker assembly [68010043]
12.Rear shelf with sun shade assembly
[68010032]
13.High mount brake light [68010008]
41
41
41
41
41
 276 
