(b) Inspect function of rear fog light.
(1) Turn the ignition switch to ON.
(2) Inspect rear fog light’s situation when every switch works, just as following table.
Light--Light System
(b) Connect joint to directional switch and inspect from wiring harness’s side joint as following table:
Avometer terminals
2-earth
2-earth
3-earth
3-earth
5-earth
6-earth
8-earth
condition
warning light switch OFF → ON
turn light switch (right) OFF → ON
warning light switch OFF → ON
turn light (left) switch OFF → ON
turn light(left) switch OFF → ON
turn light(right) switch OFF → ON
warning light switch OFF → ON
regular situation
0V → 0 ⇔ 9Vevery min 60 to 120 times
0V → 0 ⇔ every min 60 to 120 times
0V → 0 ⇔ 9Vevery min 60 to 120 times
0V → 0 ⇔ 9Vevery min 60 to 120 times
over 9V → 0V
over 9V → 0V
over 9V → 0V
2. Inspect rear fog light switch
(a) inspect rear fog light wiring
(1) Disassemble the joint from switch sides and inspect the
joint from wiring harness as following table.
Avometer terminals
1-earth
2-earth
3-earth
5-earth
6-earth
7-earth
condition
normal
light control switch OFF → ON
normal
light control switch OFF → ON
front fog light switch OFF → ON
normal
regular situation
conduct
ion
0V → 10-14V
10-14V
not conduct
ion → conduction
not conduction→ conduction
conduction
Situation
Light switch OFF → ON, front fog light switch OFF
Light switch OFF → ON, front fog light switch ON, rear fog light switch ON
rear fog light working situations
rear fog light does not light
rear fog light lights
3. Inspect lighting system function
Clues on: key aperture lamp and room light.
Avometer terminals
7-earth
1-earth
1-earth
4-earth
condition
normal
turn light switch ON
turn light switch ON
normal
regular situations
conduct
ion
battery voltage
no voltage
battery voltage
Wiring
harness side
282
