Geely FC User Manual

Anti-stealing and door lock--Electric door lock control system
2. Check front passenger seat door locker assembly
Liking that shown in figure, supply battery voltage to terminal,
and check the function of door locker.
If the function does not accord with the regulation, change the
door locker assembly.
3. Check the left rear and right rear door locker assembly.
Liking that shown in figure, supply battery voltage to terminal,
and check the function of door locker.
If the function does not accord with the regulation, change the
door locker assembly.
Open
Close
Open
Close
 360 
Condition Function
Supply battery anode to No. 6 terminal, cathode to No.5 terminal Open
Supply battery anode to No. 5 terminal, cathode to No.6 terminal Close
Condition Function
Supply battery anode to No. 6 terminal, cathode to No.5 terminal Open
Supply battery anode to No. 5 terminal, cathode to No.6 terminal Close
