Engine mechanism - Cylinder cover gasket components
(c) Tighten each cylinder head bolt in turn again.
Torque: m
(d) Install heating air water outlet pipe components.
Torque:
8. Install camshaft.
(a) Coat engine oil on camshaft journal.
(b) Put 2 camshafts on cylinder head and with cylinder 1 cam-
shaft end toward the direction shown in the diagram.
(c) Check forward remarks and figures of all bearing cover, and
tighten the bolts as sequences shown in the diagram.
Torque:
Camshaft front bearing cover:
Camshaft bearing cover:
9. Check idle speed and ignition timing.
10. Check compression pressure.
11. Check CO/HC.
