Geely FC User Manual

Inside wheel
38
o
45 2
o
Outside wheel: reference
32
o
50
Front suspension - Front wheel alignment
(Coarse road)
Inside wheel 39
o
05 2
o
Outside wheel: reference
33
o
10
Camber -0 31’ 45’
Left-right error
45’
Caster 2 42’ 45’
Left-right error
45’
Steering shaft inclination 18’ 45’
Left-right error
45’
Camber
-
0 18’ 45’
Left-right error
45’
Caster
2 30’ 45’
Left-right error
45’
Steering shaft inclination
10 52’ 45’
Left-right error
45’
A: inside
B: outside
Front
Gauge
If caster and steering axis inclination are not within specification, please adjust the caster and
then check parts of lower control arm is damaged or worn.
(b) Loosen lock nuts at the end of transversal lever .
(c) Evenly rotate end levers of left and right rack to
adjust toe-in.
Hint: try adjusting toe-in to medium value.
(d) Ensure that the end lever length of left rack equals that
of right rack.
(e) Tighten lock nuts at the end of transversal lever.
Torque: 74
5 N.m
(f) Install dust cover fixing clip.
Hint: ensure that the dust cover does not distort.
5. Inspection of turning angle
(a) Completely rotate steering wheel to the bottom and then
measure turning angle.
Turning angle:
(General road)
(Coarse road)
Wheel
alignment
tester
88
If left and right inside wheels are not within specification, please check the end lever length of left rack
and right rack.
6. Inspection of camber, caster and steering shaft inclination
(a) Install camber-caster-kingpin gauge or erect wheel alignment tester.
(b) Check camber, caster and steering-axis inclination.
Camber, caster and steering shaft inclination:
(General road)
